Structures
34.
What types of arches can you see on the front of this
building?
There are pointed arches in the lower cloister and lobed arches
in the upper cloister.
Apply
35.
In your notebook draw diagrams of the structures
on these pages. Label the structural elements, the
material used in each part of the structure and identify
the types of stress each part bears.
Stone parts mainly bear compression because this is the stress
which this material is best at withstanding.
36.
Using the development plan of an arch stone on the
right, build an arch using five pieces. Put it together
horizontally on a piece of cardboard. Raise it carefully
and check that it stays up by itself without any glue.
When making the keystones it is necessary to make sure that
the sides which support each other are flat. You can also build
a cardboard centring and place the pieces over it. In the end,
take it away and put the keystone in place.
